Professional High-Volume Haze Machine
The EUROSMOKE FZ 3000 is a high-power professional haze machine specifically designed for large venues and high-volume atmospheric applications. Built on the same technological foundation as the EUROSMOKE FZ series, it delivers exceptional output capacity while maintaining precise control and operational stability. With its powerful heating system and high-capacity airflow, the FZ 3000 is ideal for large stages, arenas, outdoor events, television studios and touring productions requiring intense and continuous haze coverage.
Equipped with an ultra-powerful internal fan and an advanced heating block, the EUROSMOKE FZ 3000 ensures rapid haze dispersion over long distances and wide areas. Its removable and service-friendly heater block allows easy maintenance and long-term performance stability. The machine integrates professional control protocols, including DMX 512 with full RDM support, enabling remote monitoring, diagnostics and configuration directly from lighting consoles or control systems.
EUROSMOKE FZ 3000
Professional High-Volume Haze Machine
The EUROSMOKE FZ 3000 is a high-power professional haze machine specifically designed for large venues and high-volume atmospheric applications. Built on the same technological foundation as the EUROSMOKE FZ series, it delivers exceptional output capacity while maintaining precise control and operational stability. With its powerful heating system and high-capacity airflow, the FZ 3000 is ideal for large stages, arenas, outdoor events, television studios and touring productions requiring intense and continuous haze coverage.
Equipped with an ultra-powerful internal fan and an advanced heating block, the EUROSMOKE FZ 3000 ensures rapid haze dispersion over long distances and wide areas. Its removable and service-friendly heater block allows easy maintenance and long-term performance stability. The machine integrates professional control protocols, including DMX 512 with full RDM support, enabling remote monitoring, diagnostics and configuration directly from lighting consoles or control systems.
Description
Technology and Features
High-Volume Continuous Output
The EUROSMOKE FZ 3000 is engineered to generate dense and uniform haze output suitable for large-scale productions. The haze output can be adjusted from 1% to 100% in 1% increments, allowing precise atmospheric control for both subtle ambience and high-density applications.
Ultra High-Performance Internal Fan
Featuring a powerful 1200 m³/h internal fan, fully adjustable from 1% to 100%, the FZ 3000 provides exceptional projection distance and wide-area coverage. This makes it perfectly suited for large halls, stadiums and outdoor stages where strong airflow is essential.
Intuitive Control Interface
The integrated LCD display with navigation wheel provides fast access to all operating parameters, allowing technicians to configure output levels, fan speed and operating modes quickly and efficiently.
Advanced Control and Connectivity
The EUROSMOKE FZ 3000 supports multiple professional control methods:
- Manual operation
- RF remote control
- DMX 512 with RDM protocol for real-time status feedback and remote diagnostics
- Timer mode for automated haze sequences
Optional accessories include WiFi DMX Remote and WiFi DMX Emitter, providing flexible wireless integration into lighting networks.
Intelligent Protection Systems
Designed for intensive professional use, the EUROSMOKE FZ 3000 includes multiple safety and protection features:
- Microprocessor-controlled temperature regulation
- Heater block protection via thermostat
- Thermal pump protection
- Integrated 16A fuse
Ideal Applications
The EUROSMOKE FZ 3000 is perfectly suited for large concert stages, festivals, arenas, theaters, TV studios, exhibition halls and major event productions. It is the ideal solution for professionals requiring strong atmospheric effects with precise control and long-term reliability.
Technical Specifications
Model: EuroSmoke FZ – 3000
Device Type: Haze Machine
Reference: 150ESM1209
Power Supply: 230V – 50Hz
Power Connector: PowerCon True1
Power Requirement: 3270 W
Heating Time: Approx. 10 minutes
Protection Rating: IP20
Fuse: 16 A
Heater Block Protection: Thermostat
Temperature Control: Microprocessor controlled
Pump Protection: Thermal switch
Tank Capacity: 5 L
User Interface: LCD display with navigation wheel and adjustment
DMX Interface: 5-pin XLR In/Out – 4-pin XLR In
Control Modes: Manual / RF Remote / DMX 512 (RDM) / Timer
Optional Accessories: WiFi DMX Remote / WiFi DMX Emitter
Internal Fan: 1200 m³/h
Fan Output Adjustment: 1% to 100% in 1% steps
Fluid Consumption (30% Continuous Mode): 50 ml/min
Fluid Consumption (100% Output): 250 ml/min
Fog Time: Approx. 1 min 30 sec
Haze Output Adjustment: 1% to 100% in 1% steps
Compatible Fluids: E-Smoke Hazer / E-Smoke 1 / E-Smoke 2 / E-Smoke 3
Dimensions:
- Length: 699 mm / 924 mm (with caps)
- Width: 397 mm
- Height: 749 mm / 755 mm (with caps)
Weight (without fluid can): 55 kg
Operating Ambient Temperature: +5 °C to +45 °C
Operating Humidity: 20% to 90% (non-condensing)
With its exceptional output power, high airflow capacity and advanced control features, the EUROSMOKE FZ 3000 is the ultimate high-volume haze solution for demanding professional environments where performance, reliability and precision are essential.
